Cast Iron Gear Pumps PGP365
Cast Iron gear Pumps PGP365
Production Introduction
POOCCAPA-PGP365 has a working pressure of up to 241bar (3,500psi) and a speed of up to 2,400rpm. The three-stage cast iron structure and low-friction bushing ensure reliability, high efficiency and long life in harsh operating environments. The displacement range is 44-147.5cc.
Name | PA-PGP356 Series Cast Iron gear Pumps |
Series | Series 365 |
Sizes | 44.3 59 73.8 88.5 103.3 118 132.8 147.5cc/rve |
Nominal | 214 bar |
Max Speed | 2400 r/min |
Operation Mode | External Gear Pumps |
Product Parameter
PGP/PGM365 Specifications | ||||||||
PGP365 Frame Size | 07 | 10 | 12 | 15 | 17 | 20 | 22 | 25 |
Displacement – cm3/rev | 44.3 | 59 | 73.8 | 88.5 | 103.3 | 118 | 132.8 | 147.5 |
(in3/rev) | 2.7 | 3.6 | 4.5 | 5.4 | 6.3 | 7.2 | 8.1 | 9 |
Max continuous pressure – bar | 241 | 224 | 207 | |||||
(psi) | 3,500 | 3,250 | 3,000 | |||||
Max Speed – RPM | 2,400 | |||||||
Approximate Weight – Lbs. | 53.5 | 56 | 58.5 | 61 | 63.5 | 66 | 68.5 | 71 |
[kg] | [24.3] | [25.4] | [26.5] | [27.7] | [28.8] | [30] | [31.1] | [32.2] |
| ||||||||
PGM365 Frame Size | 07 | 10 | 12 | 15 | 17 | 20 | 22 | 25 |
Displacement – cm3/rev | 44.3 | 59 | 73.8 | 88.5 | 103.3 | 118 | 132.8 | 147.5 |
(in3/rev) | 2.7 | 3.6 | 4.5 | 5.4 | 6.3 | 7.2 | 8.1 | 9 |
Max continuous pressure – bar | 241 | 224 | 207 | |||||
(psi) | 3,500 | 3,250 | 3,000 | |||||
Max Speed – RPM | 2,400 | |||||||
Approximate Weight – Lbs. | 53.5 | 56 | 58.5 | 61 | 63.5 | 66 | 68.5 | 71 |
[kg] | [24.3] | [25.4] | [26.5] | [27.7] | [28.8] | [30] | [31.1] | [32.2] |
Detail Image
Poocca PGP/M365 series fixed displacement gear pumps offer high pressure durability due to their cast iron construction, making them ideal for high duty cycle mobile applications for the Construction, Forestry, and Oil Gas markets. They are available as a standard pump, clutch pump, and tandem pump.
Features/Benefits:
• Three-piece cast iron construction for distribution flexibility
• Cast Iron construction for durability
• Balanced Thrust Plates minimize friction and leakage
• Journal bearings for long life
• Multiple sections available
Technical Specifications:
• Flow range to 93.5 gpm (354 lpm) per section
• Displacements from 2.79 to 9 cir (44 to 147.5 cc/rev)
• Operating pressures up to 241 bar (3,500 psi)
• Speeds up to 2,400 rpm
• Volumetric efficiencies up to 98%
• CW, CCW, and Bi-rotational pumps available
• SAE and SI shafts, flanges and porting available
• Multiple section, as well as Cross frame add-a-pumps
• Extensive integrated valve capabilities
- Load sense flow control
- Relief with anti-cavitation check
- Priority flow control
- Solenoid unloaded relief valve
Application
PARKER PGP365 series gear pumps are used in material handling, maintenance, agriculture, construction equipment and so on.
This series of pumps is a three-stage cast iron structure and is a low-friction bushing. This bushing can ensure reliability in harsh operating environments, has high efficiency and long life, and its displacement range is 44-147.5cc.
Why should we choose PARKER PGP365 series gear pump?
①Single function and multiple function configurations can be used.
②Internationally used high-performance bushing pump
③The pressure-balanced bearing seat ensures maximum efficiency under any working conditions
④Excellent performance, high efficiency and low noise under high working pressure
⑤High-strength materials and large shaft extension diameter reduce the bearing load under high working pressure.
FAQ
1. What brand alternatives can you provide? Is there an original?
We can provide the original or replacement of the following brands: Parker, Rexroth, Yuken, Denison, Vickers, Marzocchi, Shimadzu, Char lynn Eaton, CML, Nachi, Daikin, Yeoshe, Sunny, Sauer Danfoss ect...
2. Do you have a showroom?
Yes, the showroom has a full range of products.
3. Can it be customized for customers?
Yes, we can customize according to your needs, we have a research and development department, our designers can design for you, and our technicians can make prototypes.
4. When will the prototype be manufactured?
Approximately 7 days after you confirm the drawings we made for you.
5. What is the lead time for mass production?
About 25 days.
Know More Models
PGP365A198*EFAB22-7
PGP365A378*CWEB12-7
PGP365A178ETAB22-7
PGP365A478EFAB17-7
PGP365B478EVAB15-7HSAB10-1
PGP365A642*VCEB17-11
PGP365A178EWAB12-11
PGP365B198EFAB22-11
PGP365A178ETAB17-7
PGP365A278SEAB25-11
PGP365A498ERAB17-7
PGP365B278**AB15-7**AB15-1
PGP365B1278*IBAB17-7FDAB15-1
PGP365B478BTAB12-7**AB12-1
PGP365B578SEAB15-7*SHAB15-1
PGP365B242IBAB17-11**AB12-1
PGP365C598IBAB17-7DAAB07-1
PGP365B278***AB17-7//PGP330A**
PGP365B298***AB12-7//PGP330A**
PGP365B178**AB10-11
PGP365B198ESAB25-11/PGP330A197
PGP365B178**AB12-7**AB10-1
PGP365B478**AB15-7CPAB10-1/PGP
KIT,SERV=PGP365A*278**AB15-11
KIT,SOFT_GOODS=PGP365/465(2GR
PGP365B298***AB22-7/PGP511A019
KIT,SERV=PGP365B598IBAB12-7**
PV140R1K1C4NFFC+PGP365A198*EFA
PGP365A178ERAB20-7
PGP365A178ERAB10-11
PGP365L578BIAB15-7**AB12-1
PGP365B278NOAB15-7CHAB10-1
PGP365B478EKAB22-11HCAB15-1
PGP365A1978*SEAB25-11
PGP365A542SEAB22-11
PGP365A198EFAB20-11
PGP365A197EWAB12-25
PGP365A278GEAB20-7
PGP365B278***AB17-7//PGP330A**
PGP365B178**AB17-7/PGP330A**AB
PGP365B178**AB22-11
PGP365B478**AB17-7/PGP330B**AB
KIT,SOFT_GOODS=PGP365(2GR)SEAL
PGP365A278SEAB20-7
PGP365A478ESAB15-11
PGP365A542REAB22-7
PGP365B178BIAB07-7**AB07-1
PGP365B478BIAB20-7UCAB20-1
PGP365B598IBAB15-7DAAB07-1
PGP365B498**AB17-7//PGP315A193
