Hydraulic Gear Pump PGP517
Aluminum Gear pumps PGP517
Production Introduction
Poocca’s Aluminum Pump PGP517 Series fixed displacement gear pump offers high performance and high power density due to its aluminum construction.
Name | PA-PGP517 Series Aluminum Gear pumps |
Series | Series 517 |
Sizes | 14 16 19 23 25 28 33 36 38 44 52cc/rve |
Nominal Pressure | 275 bar |
Maximum Pressure | 300 bar |
Operation Mode | External Gear Pumps |
Product Parameter
PGP/PGM517 Specifications | ||||||||||||
Description | Code | 0140 | 0160 | 0190 | 0230 | 0250 | 0280 | 0330 | 0360 | 0380 | 0440 | 0520 |
Displacements | cm3/rev in3/rev | 14 | 16 | 19 | 23 | 25 | 28 | 33 | 36 | 38 | 44 | 52 |
0.85 | 0.98 | 1.16 | 1.4 | 1.53 | 1.71 | 2.01 | 2.2 | 2.32 | 2.68 | 3.17 | ||
Continuous Pressure | bar | 250 | 220 | 200 | ||||||||
3625 | 3190 | 2900 | ||||||||||
Intermittent Pressure | bar | 275 | 255 | 220 | 215 | |||||||
3988 | 3698 | 3190 | 3118 | |||||||||
Minimum Speed @Max. Outlet Pressure | rpm | 500 | ||||||||||
Maximum Speed @ 0 Inlet & Max. Outlet Pressure | rpm | 3400 | 3300 | 3100 | 3000 | 2800 | 2600 | |||||
Pump Input Power @ Max. Pressure and 1500 rpm | kW | 9.6 | 11 | 13.1 | 15.8 | 17.2 | 19.3 | 22.7 | 24.6 | 26.1 | 27 | 28.6 |
12.87 | 14.75 | 17.57 | 21.19 | 23.07 | 25.88 | 30.44 | 32.99 | 35 | 36.21 | 38.35 | ||
Dimension “L” | mm | 68.3 | 70.3 | 73.3 | 77.4 | 79.4 | 82.4 | 87.5 | 90.5 | 92.5 | 98.6 | 106.7 |
2.69 | 2.77 | 2.89 | 3.05 | 3.13 | 3.24 | 3.44 | 3.56 | 3.64 | 3.88 | 4.2 | ||
Approximate Weight * | kg LB | 7.92 | 8 | 8.12 | 8.29 | 8.37 | 8.5 | 8.7 | 8.83 | 8.91 | 9.16 | 9.49 |
17.5 | 17.68 | 17.95 | 18.32 | 18.5 | 18.79 | 19.23 | 19.51 | 19.69 | 20.24 | 20.97 | ||
*Single pump with Shaft End Cover H3 and non ported Port End Cover. | ||||||||||||
Detial Image
Poocca's Aluminum Pump PGP517 Series fixed displacement gear pump offers high performance and high power density dues to its aluminum construction, making it an ideal selection for the Aerial, Agriculture, Construction, Forestry, Material Handling, and Turf Equipment markets. It is available as a standard pump, clutch pump, tandem pump or as a pump with a priority flow valve including primary circuit relief valve.
Features/Benefits:
• Three-piece construction for distribution flexibility
• Aluminum pumping sections for light weight
• Journal bushings for long life
• Pressure balanced thrust blocks for high efficiency
• Multiple sections available
Applications:
• Power steering pumps – priority valves available
• Brake pump
• Brush Chipper
• Trencher pump
• Hydraulic Power Unit
• Aerial Lift
• Transfer pump
• Lube pump
Technical Specifications:
• Sizes from 16 to 70 cc
• Operating pressures up to 275 bar (3,988 psi)
• Speeds up to 3,400 rpm
• CW, CCW, and Bi-rotational pumps available
• SAE shafts, flanges and porting available
Application Introduction
Gear oil pump The gear pump is an external gear pump with axial flexibility compensation and radial hydraulic balance.
Gear oil pump series gear pumps can be composed of double pumps and quadruple pumps.
Can provide various flanges, shaft extensions, and oil inlet and outlet connections that comply with SAE and.
Gear oil pump series gear pumps are widely used in hydraulic systems of tractors, construction machinery and other machinery.
PGP517 multi-pump gear oil pump gear pump is an external gear pump with axial flexibility compensation and radial hydraulic balance.
Gear oil pump Gear pump can be composed of double pump and quadruple pump. Can provide a variety of flanges, shaft extensions, in and out in accordance with SAE and
Gear oil pump series gear pumps are widely used in hydraulic systems of tractors, construction machinery and other machinery
FAQ
Where is your factory?
In Shenzhen, China.
When was your factory established?
Since 2005
What is your main market?
Europe, North America, South America, Australia, Middle East, etc.
What type of product is yours?
We provide various types of hydraulic gear oil pumps, hydraulic vane oil pumps, hydraulic piston oil pumps, hydraulic oil motors, hydraulic accessories, hydraulic valves, etc.
Where are your products used?
Industrial equipment, agricultural machinery, excavators, forklifts, cranes, pump trucks, sanitation, garbage trucks, metallurgical equipment, injection molding machinery, etc.
Know More Models
PGP517M0520CT2D5NJ9J8B1B1
PGP517A0160CD1H3MP2P2B1B1
PGP517A0360CT5T7TP4B1*B1D5
PGP517A0520CD1H3VP4P3A1*H2*
PECOV PGP517-503
PGP517A0260AD1H9WP3P2B1B1
PGP517A0190AD1H3*VJ9J8B1B1
PGP517A0440AD1H3VP4P3A1*H2*
PGP517A0520AD1H3VP4P3A1*H2*
PGP517A0440CE1H3VP5P3A1*H2*
PGP517A0230CD1H3NE7E6A1*H2*
PGP517A0440AE1K6*NT4T4RYAG
PGP517A0380CC2H2NE7E6C2*H2*
PGP517A0580AM3*K6NT4*T4*B1B1
PGP517A0140AD1H3VT3T2A1*H2*
PGP517A0580CD1K6VP4*P3*B1B1
PGP517A0230AD1H3NE7E6C2*H2*
PGP517A0380AC1H2NE7E6C2*H2*
PGP517A0380AD1H3ND7D6C2*H2*
PGP517A0360CT5T5TT4B1*B1D5
PGP517A0310CC1H2MD6D5B1B1
PGP517A0440CD1H3NP4P3A1*H2*
PGP517A0440AD1H3NP4P3A1*H2*
PGP517A0290AD1H2*NJ9J7*B1B1
PGP517M0520AC1H2ND7D6D7*D6*
PGP517M0120CS9L5ND6*D5*D6D5
PGP517M0190CS9L5ND6*D5*D6D5
PGP517M0230CD1H3ND6*D5*D6D5
Parker Hannifin • PGP517 Series, 165 - 250 Bar (Aluminium) • P17A196BEFB44-65
PGP517A0260C**H5NB1J8E6B1
PGP517A0260C**H5NB1J7E6B1
PGP517A0700AD1H3VP5P3*B1B1
PGP517A0280CC1H2VH8H6C2*H2*
PGP517A0230AC2H2VH8H6C2*H2*
PGP517A0250AC2H2VH8H6C2*H2*
PGP517A0380CD1H3ND7D6****
PGP517M0160CS9L5ND6*D5*D6D5
PGP517M0230CS9L5ND6*D5*D6D5
PGP517M0440CS9L5ND7*D6*D7D6
PECOV PGP517-505 CCW
PGP517A0190CD1H3NP3P2A1*H2*
PGP517A0290AD1H2*NJ9J5*B1B1
PGP517A0250AD1H3ND6D5A1*H2*
PGP517A0330CD1H3VP4P3A1*H2*
Parker Hannifin • PGP517 Series, 165 - 250 Bar (Aluminium) PGP517A0330CD1H3NJ9J8B1B1*
Parker Hannifin • PGP517 Series, 165 - 250 Bar (Aluminium) P17A196BEBB28-65
PGP517A0380AC2H2NE7E6C2*H2*
PGP517A0280AC1H2VH8H6C2*H2*
PGP517M0250CD1H3ND7*D6*D7D6
