Settima SMT16B Screw Pump

Settima SMT16B Screw Pump

Parameter







Suction	3" 1/2 (SAE-3000)
Discharge	3" (SAE-3000)
Key	10 mm
Fitting front flange	200 mm
Flange	ISO 3019/2
Connections	SAE 3000 - BSPP
Sealing	NBR
Min. speed	500 rpm
Max. speed	3600 rpm
Inlet pressure	0.7 - 3 bar
Environment temperature	- 50 ° - + 60°C
Oil temperature	-20° - +180°C
Viscosity range	Until 100 cSt
Acoustic emissions	52 - 68 db(A)
Rotation	CW
Body materiaal	Aluminium
Max. pressure	40 bar
Flow at 3000 rev/min	800 l/min
Flow at 1500 rev/min	400 l/min
Ø Flange	300 mm
Ø Shaft	32 mm
Shaft type	Cylindrical shaft
Submersible	No
Internal code	GR70-SMT16B-800L
Datasheets	For additional product information see datasheet(s)



Dimension





Suction and drain hole confguration available as per table below (orientations relative to pressure port).Confqurazioni di porte di aspirazione, mandata e drenaggio. Vedi tabella sotto.

Standard confguration / confgurazioni standard
Standard confquration:T1-D2
Confqurazione standard:T1-D2
Standard confguration for pumps WITH RP VALVE:T4-D2
Configurazione standard perpompa CON VALVOLA RP: T4-D2

Settima recommends that in case of request of pump with RP valve (external variable regulation valve), it is necessary to choose very carefully the suction and drain confguration. Once the external valve is built on the pump it will be not possible any change of both confgurations.
Settima raccomanda disceqliere attentamente laconfqurazione delle porte nel caso di pompa con valvola RP (valvola regolazione variabile esterna). La valvola RP impedisce di modifcare lorientamentodelle porte una volta installata sulla pompa.
