Dana Brevini S5AV Piston Pump S5AV032/045/050/063/075/093

Dana Brevini S5AV Piston Pump S5AV032/045/050/063/075/093



Features



The S5AV hydraulic piston pump is a compact, low-noise pump with a swash plate design and high-performance rotating components that can operate stably at high continuous and peak pressures. Its patented piston slider design can effectively reduce leakage, improve volumetric efficiency, and ensure excellent pump performance.



This series of pumps has a continuous operating pressure range of 280 to 350 bar (4060 to 5080 psi), a peak pressure of 350 to 420 bar (5080 to 6090 psi), and a speed range of 300 to 1800 rpm, suitable for a variety of industrial applications.



Displacement



			Dana Brevini S5AV Piston Pump Size
			032	045 050 063 075						093
Displacement (1)	V g max	cm3/rev [in3/rev]	32.00 [1.95]		43.3 [2.64]	49.65 [3.05]	63.98 [3.90]	75.00 [4.57]	93.76 [5.72]
Displacement (1)	g min	cm3/rev [in3/rev]	0 [0]		0 [0]	0 [0]	0 [0]	0 [0]	0 [0]
Press. max. cont.	pnom	bar [psi]	280 [4000]		300 [4350]	320 [4600]	320 [4600]	350 [5000]	320 [4600]
Press. max. peak	pmax	bar [psi]	350 [5000]		350 [5000]	380 [5500]	380 [5500]	420 [6000]	380 [5500]
Max speed at Vg max(1)	n max nom	rpm	3150		2700	3000	2500	2250	2100
Minimum Recommended Speed	n min	rpm	500		500	500	500	500	500
Max flow at n max nom e Vg max	qmax nom	l/min [U.S.gpm]	100 [26.4]		117 [30.88]	149 [39.3]	160 [42.24]	169 [44.62]	197 [52]
Max power at qmax nom e pnom	P max nom	kW [hp]	46 [62]		57 [76]	79 [105]	85 [114]	113 [151]	121 [162]
Torque constant	Tk	Nm/bar [lbf.ft/psi]	0.51 [0.026]		0.69 [0.035]	0.79 [0.040]	1.01 [0.052]	1.20 [0.061]	1.49 [0.076]
Max torque cont. at pnom	T nom	Nm [lbf.ft]	142 [105]		207 [152.5]	253 [186]	326 [240]	418 [308]	477 [351]
Max torque peak at pmax	T max	Nm [lbf.ft]	177 [130]		241 [177]	300 [221]	387 [285]	500 [368]	567 [418]
Moment of inertia (2)	J	kg·m2 [lbf.ft2]	0.0034 [0.081]		0.0034 [0.081]	0.0065 [0.154]	0.0065 [0.154]	0.0098 [0.232]	0.0098 [0.232]
Weight (2)	m	kg [lbs]	19 [42]		20 [44]	30 [66]	31 [68]	42 [92]	44 [96]





Dimensions
